Maxon AF-F1 Auto Filter

Maxon AF-F1 Auto Filter

Made in Japan.

From the later Maxon Fire Blade series, after the Maxon/Ibanez AF-9 and AF-01 Auto Filter models.

Like most auto filters this pedal is largely based on the Mu-Tron III design and controls. Sounds great, works perfect and is in excellent physical condition. Multiple parameter settings for a wide variety of filter/envelope effects. For some reason this series from Maxon were labelled as being 10V (like some of the reissue series), though they work perfectly on standard 9VDC and take a regular Boss-type (not included) or 9V battery. No more etiquette at the back side.

Specs:

Input Impedance500K Ohms

Output Impedance10K Ohms

Residual Noise-100 dB or less (input shorted IHF-A weighted)

Filter Frequency100 Hz ­ 2 KHz (Low) / 200 Hz ­ 4 KHz (High)

Power VoltageDC9 V (Battery) / DC10 V (AC-adaptor)

Current Consumption19mA/DC.9V

Dimensions78(W) x 135(D) x 54(H)mm

Weight420g

Comes as described.
